Setting up HomeSeer to use TEMP08

Introduction  Description Schematic Instructions  Software Vintages  Differences with TEMP05  FAQ  HomeSeer Setup References Ordering Information Download the Instruction Manual Here

  Please Read the FAQ's

(we're not kidding - we get a lot of e-mails with questions that are already addressed in the Frequently Asked Questions web page)

Note 1: Blade has developed a plug-in that is compatible with TEMP08.  It is described on the HS website here.

Note 2: Ken Mitchell has written a HomeSeer Plug-in for the TEMP05 which can be used for the TEMP08.  This plug-in eliminates the need for the script shown on this page. The beta forum for the plug-in is located here.

Note 3: Michael McSharry has also written a HomeSeer Plug-in for the TEMP05/08 which adds a database capture and charting.   That plug-in can also be used for the TEMP08 The forum is located here.

Note 4: An alternate stand-alone application is available as thermd .

Note 5: The script information on this page refers only to TEMP08.

1. Make sure that TEMP08 is connected to your COM1 serial port on your HS PC.  If it is not, rename the script below (COM1_EVENT.TXT) to whatever COM port that TEMP08 is connected to.  Save that script in your HomeSeer Scripts folder.
2. Add the following lines to your "startup.txt" HS script (put them anywhere before the "end sub" line);

3. Change the red numbers from 1 to whatever com port you are using.
4. Add the following lines to your "shutdown.txt" script (again, anywhere before the "end sub");

5. Shutdown HS and then restart it.  You should see the "COM1   setup complete" message in your log.
6. Add virtual X-10 devices R1 through Rx (where x is the number of sensors that you have).  Define them as "status only" and create a new device type for them (doesn't matter what you call it).
7. If you have a humidity sensor connected, create a virtual device R20 for it.  If you have multiple humidity sensors, create multiple virtual devices, starting at R20.
8. If TEMP08 is connected to the proper COM port, then you should, within a minute (or whatever sampling time you set in TEMP08), start seeing at least one valid temperature in virtual devices R1-x.  If you have all your sensors connected, then all of the virtual devices should be showing valid temperatures.
9. If you want to generate a web page using these virtual devices, go here.
10. to download a text version of the com1_event script, go here.

SCRIPT COM1_EVENT.TXT

' this script reads data from TEMP08 and stores received sensor readings into HS virtual devices
' Modified by Mitch Matteau 07-01-23    added virtual device update to switch reading

' Modified by Mitch Matteau 04-04-30    added "true" parameter to all hs.setdevicestring function calls

' Created by Mitch Matteau 02-12-21
'=============================================================
' HS virtual devices used;
' r1 to r19 for DS18S20 sensors
' r20-29 for humidity sensor
'=============================================================
sub main(data)
'=============================================================
dim i
dim result
dim virt_device
dim default_hc
dim prev_result
dim wind_dirn
dim wind_spd
dim wind_gust
dim high_wind
dim rain_history
dim rain_today
dim rain_absolute
dim SwitchStatus
dim SwitchNumber
dim SwitchBase

dim SwitchValue

' virtual device list
default_hc = "r"
wind_dirn = "z7"
wind_spd = "z4"
wind_gust ="z1"
high_wind = "v6"
rain_history = "v8"
rain_today = "v7"
rain_absolute = "v9"
SwitchBase = "s"
'=============================================================
' Check if the received data is from a temperature reading
'=============================================================
if mid(data,1,4)="Temp" then
    sensorid = mid(data,7,2)
    if left(sensorid,1) = "0" then
        sensorid=mid(sensorid,2,1)
    end if
    i = Instr(data,"=")
    result=trim(mid(data,i+1))
    if right(result,1)="F" or right(result,1)="C" then
        result = left(result,(len(result)-1))
    end if
    if CInt(sensorid)<=19 then
        virt_device=default_hc+sensorid
        prev_result=hs.DeviceString(virt_device)
    end if
'=============================================================
' eliminate false readings
' false readings are replaced with the previous reading
'=============================================================
    if left(result,3) = "???" then
        result = prev_result
    end if
        if left(result,3) = "185" then '185 is an indicator that the device result is invalid
        result = prev_result
    end if
'=============================================================
' Now save current readings into HomeSeer
'=============================================================
    hs.SetDeviceString virt_device,result,true
    if result<>prev_result then
        hs.SetDeviceLastChange virt_device, Now()
        hs.SetDeviceValue virt_device,result
    end if
end if
'=============================================================
' Humidity Sensor Capture
'=============================================================
if left(data,10)="Humidity #" then
    i=Instr(data,"#")
    sensorid=mid(data,i+1,2)
    if left(sensorid,1) = "0" then
        sensorid=mid(sensorid,2,1)
    end if
    virt_device=default_hc+CStr(CInt(sensorid)+19)
    prev_result=hs.DeviceString(virt_device)
    i = Instr(data,"=")
    result = Trim(mid(data,i+1))
    if result="???" then
        result=prev_result
        hs.Writelog "Humidity","Sensor error on #"+sensorid
    end if
    hs.SetDeviceString virt_device,result,true
    if result<>prev_result then
        hs.SetDeviceLastChange virt_device, Now()
    end if
end if
'=============================================================
' Version capture
' virtual device z17 used to capture the data
'=============================================================
if mid(data,1,6)="TEMP08" then
    version_id = "z17"
    hs.SetDeviceString version_id,data,true
    hs.SetDeviceLastChange version_id, Now()
end if
'=============================================================
' Relay Status capture
' virtual devices z31 through z38 used to capture the data
'=============================================================
if mid(data,1,5)="Relay" then
    i = Instr(data,"=")
    data = mid(data,i+1)
    for i=1 to 8
        virt_device= "z3"+trim(CStr(i))
        a = trim(hs.StringItem(data,i,","))
        if a<>hs.DeviceString(virt_device) then
            hs.SetDeviceString virt_device,a,true
            hs.SetDeviceLastChange virt_device,Now()
        end if
    next
end if
'=============================================================
' Wind Direction capture
'=============================================================
if left(data,9)="Wind Dirn" then
    result = mid(data,10)
    position = InStr(result,"=")
    if position<>0 then
        a = mid(result,position+1) ' wind direction
        if a <>"???" then
            hs.SetDeviceString wind_dirn,a,true
            hs.SetDeviceValue wind_dirn,0
        end if
    end if
end if
'=============================================================
' Wind Speed capture
'=============================================================
If left(data,10)="Wind Speed" Then
    result = mid(data,11)
    position = InStr(result,"=")
    If position<>0 then
        result = mid(result,position+1)
        a = hs.StringItem(result,1,",") 'wind speed
        a = Trim(replace(a,"MPH",""))
        If left(a,3)<>"???" then
            hs.SetDeviceString wind_spd,a,true
            hs.SetDeviceValue wind_spd,CInt(a)
        else
            a=0
        end if

        b = hs.DeviceString(high_wind)
        if isnumeric(b) then
            b = CInt(hs.DeviceString(high_wind))
        else
            b = 0
            hs.SetDeviceString high_wind,"0",true
            hs.SetDeviceLastChange high_wind, Now()
        end if

        if Cint(a) > CInt(b) then
            hs.SetDeviceString high_wind,CStr(a),true
            hs.SetDeviceLastChange high_wind, Now()
            hs.WriteLog "HIGH WIND",a+" mph"
            hs.CreateVar("HWNDT")
            hs.SaveVar "HWNDT",Time()
        end if

        a = trim(replace(hs.StringItem(result,2,","),"Gust = ",""))
        hs.SetDeviceString wind_gust,a,true
        hs.SetDeviceValue wind_gust,CInt(a)
    End if
end if
'=============================================================
' Rain Counts
'=============================================================
if Left(data,4)="Rain" Then
    position=InStr(data,"=")
    If position<>0 then
        b = mid(data,position+1) ' rain count
        If left(b,3)<>"???" then
            b = trim(replace(b," Inch","")) ' remove units
            c = hs.DeviceString (rain_history) ' History Info
            a = hs.StringItem(c,7,",") ' Yesterday's count
            hs.SetDeviceString rain_absolute,b,true ' absolute rain count
            hs.SetDeviceLastChange rain_absolute, Now()
            If IsNumeric(b) then
                l = CSng(b) ' Value of Absolute count

                If Not IsNumeric(a) then
                    k = l ' on error, assume no count
                Else
                    k = CSng(a) ' Value of Yesterday's count
                End If

                If (l-k) > 10 then
                    a = "0.00" ' can't do more than 9 inches in 1 cycle
                Else
                    a = CStr(Round((l-k),2)) ' Result is today's count
                End If

                If IsNumeric(a) then
                    hs.SetDeviceString rain_today,a,true ' Today's count
                    hs.SetDeviceValue rain_today,CInt(a)
                    d = ""
                    For i = 1 to 7
                        d = d + hs.StringItem(c,i,",")+","
                    Next
                    d = d + b
                    hs.SetDeviceString rain_history,d,true ' Restore history info
                    hs.SetDeviceLastChange rain_history, Now()
                End If
            End If
        End If
    End If
End If
'=============================================================
' Switch Status Capture and transfer
'=============================================================
if Left(data,6)="Switch" Then
    SwitchNumber = SwitchBase+mid(data,Instr(data,"#")+1,2)
    SwitchStatus = mid(data,Instr(data,"=")+1,3)
    if left(SwitchStatus,2)="On" then
        SwitchStatus="On"

        SwitchValue = 2
    end if
    if left(SwitchStatus,3)="Off" then
        SwitchStatus="Off"
        SwitchValue = 3
    end if

' use one of the following to report the switch status to an X-10 or virtual device:
'hs.execX10 SwitchNumber,SwitchStatus,0

'hs.setdevicevalue SwitchNumber,SwitchValue

end if
'=============================================================
' use the following to debug your connection to TEMP08...

hs.writelog "TEMP08 RECEIVED",data

end Sub
